Streaming, throughput, and the KV cache

Watch a chat model type out an answer one token at a time. That's not a loading animation. The model genuinely produces one token, runs again to get the next, runs again for the one after that. Streaming is just the decision to show you each token the moment it lands instead of waiting for the whole thing.

This is post 4 of 13 in the Local LLMs series. By the end of it you'll know what time-to-first-token actually measures, why streaming tricks you into thinking the model is faster, and the one optimization (the KV cache) that makes a 1,000-token reply cost far less than running the model 1,000 times.

How an LLM produces output

Inference runs in two phases.

• Prefill. The model reads your whole prompt at once. Every input token goes through every layer in parallel. The GPU eats this for breakfast, because big matrix multiplies are precisely what GPUs are built for.
• Decode. The model generates one token. To get the next one it has to "see" everything so far, your prompt plus the tokens it just wrote. Then it repeats, over and over, until it hits a stop token or a length limit.

Prefill is fast, thousands of tokens per second on consumer hardware, because it all happens at once. Decode is slow, 30 to 120 tok/s on the same hardware, because each token depends on the one before it. You can't parallelize a sequence you haven't generated yet.

Two numbers describe this.

• Time-to-first-token (TTFT). How long from hitting enter to the first character showing up. Prefill dominates it. Short prompt, milliseconds. A 50K-token prompt, several seconds.
• Tokens per second (tok/s). How fast the model spits out output once decode starts. This is the typing speed.

A reasonable Llama 3.2 3B run on a 16GB MacBook Air gives you TTFT around 100ms for a short prompt and decode around 35 tok/s. About as fast as a brisk human reader.

Why streaming feels faster

Same token count, same total time. But streaming starts showing output right away, and that changes everything about how it feels.

• Perceived latency collapses to TTFT. Something appears within 100ms even if the full reply takes 8 seconds.
• You read while the model writes. Reading and generation overlap instead of stacking.
• You can kill it mid-flight. If the answer is clearly going sideways by token 50, you stop it. With one-shot output you sit through the whole 8 seconds and only then find out it was wrong.

The only good reason to use one-shot output is when you need the complete answer before you can do anything with it: parsing JSON, firing a tool call, shipping the result somewhere. Everywhere else, stream.

Both modes are first-class on every local runtime. Ollama returns streaming JSON by default. LM Studio's OpenAI-compatible server streams through the stream: true flag. llama.cpp has its --stream flag.

The KV cache, finally

Here's the question that's been sitting under all of this. To generate token #1000, the model needs to "see" tokens 1 through 999. So does it reprocess all 999 every time it wants the next one? That would be quadratically expensive and nobody could afford it.

It doesn't. It uses the KV cache.

The mechanic: every layer of a transformer has a self-attention block. Self-attention computes three things from each input token, a Query (Q), a Key (K), and a Value (V). Each new token's Q gets checked against every prior token's K and V to work out what to pay attention to.

The trick: K and V for past tokens never change. Once they're computed, they're fixed forever. So you cache them. To generate token #1001 the model only computes Q for the new position and looks up K and V for everything before it. The work per new token stays roughly flat no matter how many came before.

Without the KV cache, token #1000 costs about 1000x token #1, and inference is unworkably slow. With it, token #1000 costs about 1x token #1 plus a small lookup, and inference actually works.

Every modern LLM runtime ships a KV cache. It is not optional. It is the thing that makes long contexts and long outputs possible at all.

What the KV cache costs

It lives in memory, and the size scales with three things.

• Context length. More tokens means more cached K and V.
• Model dimensions. More layers and a bigger hidden size means more K and V per token.
• Batch size. Each parallel request carries its own cache.

A rough formula for a single sequence:

KV cache size ≈ 2 × layers × hidden_size × context_length × bytes_per_value

For Llama 3.1 8B at FP16 across the full 128K context, that's about 16 GB just for the cache. The weights are 16 GB too. The cache can match them.

This is why a 16GB GPU runs an 8B model fine at 4K context but blows up at 128K. The wall isn't the weights. It's the KV cache.

What that means in practice:

• Pick a context length you actually use. Most chat never needs 128K. Set n_ctx to 8K or 16K and pocket the gigabytes.
• Watch RAM and VRAM climb as the conversation grows. The cache grows with every turn.
• When you OOM on "long conversations" but never at startup, the KV cache is your culprit.

KV cache quantization

Same idea as quantizing weights, pointed at the cache instead. Q8 KV cache uses 1 byte per value rather than 2. Q4 KV cache uses 0.5 bytes.

The savings are big. That same Llama 3.1 8B at 128K context drops from 16 GB of KV down to 8 GB at Q8, or 4 GB at Q4.

Q8 costs you almost nothing in quality. Q4 costs a bit more. Most people should turn on Q8 KV cache by default and never think about it again. Ollama and llama.cpp both support it, and LM Studio exposes it in advanced settings.

# llama.cpp server with Q8 KV cache

./llama-server -m model.gguf -c 16384 --cache-type-k q8_0 --cache-type-v q8_0

Ollama's equivalent is the OLLAMA_KV_CACHE_TYPE=q8_0 environment variable.

The first time you flip this on and watch your 8B model hold 32K context where it used to die at 16K, you'll wonder why it isn't the default everywhere.

A worked example

You're chatting with Llama 3.1 8B Q4 on a 16GB MacBook Air. Here's the setup.

• Model weights at Q4: ~5 GB
• Context length: 8K
• KV cache at FP16, 8K context: ~1 GB
• Runtime overhead: ~0.5 GB
• Total VRAM: ~6.5 GB. Fits comfortably.

Then you crank context to 32K because someone told you more context is always better.

• Weights: 5 GB (unchanged)
• KV cache at FP16, 32K: ~4 GB
• Total: ~9.5 GB. Still fits.

So you push to 128K.

• KV cache at FP16, 128K: ~16 GB
• Total: ~21 GB. Doesn't fit. OOM.

Now you enable Q8 KV cache and try 128K again.

• KV cache at Q8, 128K: ~8 GB
• Total: ~13 GB. Fits.

Same model, same hardware. One configuration knob decided whether 128K context was even possible.

TTFT on long prompts

Prefill runs in parallel, but it's still proportional to how big your prompt is. A 50K-token prompt has to flow through every layer once before a single output token can appear. On a 4090 that's roughly 1 to 2 seconds for a 7B model. On a MacBook Air, 4 to 8 seconds.

If your app feeds in long prompts and still needs a fast first response, the fix is prefix caching, which some runtimes call "prompt caching." If the same long prefix shows up at the start of two requests, you cache it after the first prefill and skip the work the second time around. Ollama does this for repeat requests with stable system prompts. llama.cpp controls it with the --cache-reuse flag.

It's the local-LLM version of the prompt caching feature in cloud APIs (post 6 of the Running series, if you got to that one).

What's next

You now know how the model produces text and why the KV cache has to exist. The next post is the practical one: which model do you actually pick? Coding, chat, summarization, structured output, multimodal, embeddings. Every task has a 2026 leader, and they are not all the same model.
